BH1313 Reinforced Grid 3-Runner
A 1300 × 1300 mm reinforced grid pallet with a 170 mm structural depth for broad square unit loads. Its equal-sided deck keeps centered loads balanced while the deeper section gives steel reinforcement more working depth.
Request a Quote- Dimensions
- 1300 × 1300 × 170 mm
- Reference weight
- 30.5 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue or custom
- Structure
- Reinforced grid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 6–12 tubes
- Static load
- 6,000 kg
- Dynamic load
- 2,000 kg
- Rack load
- 1,600 kg
AS/RS Performance Shaped Around This Footprint
Deep square structure for centered heavy loads
The large square deck is well suited to drums, bulk packs and carton arrays that spread in both directions. Compared with a rectangular footprint, it simplifies load centering and leaves similar edge allowance on all four sides.
Automated handling characteristics
At 170 mm high, BH1313 uses section depth to support a stable shape across a broad plan area. Three runners still establish a clear travel direction for rack and conveyor support, even though the upper deck is square.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
