BH1410 Reinforced Grid 3-Runner
A long 1400 × 1000 mm reinforced grid pallet for wide cartons, production fixtures and loads that need extra length without an oversized width. The 150 mm profile retains a compact vertical interface.
Request a Quote- Dimensions
- 1400 × 1000 × 150 mm
- Reference weight
- 28.5 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue or custom
- Structure
- Reinforced grid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 6–12 tubes
- Static load
- 6,000 kg
- Dynamic load
- 2,000 kg
- Rack load
- 1,600 kg
AS/RS Performance Shaped Around This Footprint
Extra deck length without excessive width
The 1.4:1 footprint follows elongated goods more closely than a square pallet and reduces unsupported product overhang at the ends. A 1000 mm width remains practical for controlled aisle and conveyor envelopes.
Automated handling characteristics
The reinforced grid and continuous runners distribute the longer load toward defined transfer points. This format is useful where the automation path is length-oriented and the unit load maintains one consistent direction.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
