BH1311 Grid 3-Runner
An intermediate 1300 × 1100 mm footprint for loads that need more length than square 1100 mm pallets without moving into a large-format platform. It gives rectangular cartons, equipment assemblies and returnable containers better end support in a controlled width.
Request a Quote- Dimensions
- 1300 × 1100 × 150 mm
- Reference weight
- 23.5 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue or custom
- Structure
- Grid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 4–8 tubes
- Static load
- 4,500 kg
- Dynamic load
- 1,500 kg
- Rack load
- 1,200 kg
AS/RS Performance Shaped Around This Footprint
Extra length where 1100 mm is not enough
BH1311 extends the load platform to 1300 mm while retaining a controlled 1100 mm width. It fits rectangular cartons, equipment assemblies and returnable containers that would otherwise overhang a square pallet, yet remains more compact than the 1400 mm and 1500 mm ranges.
A clear path through rack and conveyor interfaces
Continuous runners along the 1300 mm axis support long bearing lines and a consistent transfer direction. The proportion also makes load orientation obvious to sensors and operators, useful when the AS/RS stores a dedicated family of rectangular unit loads.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
