BH1412B Grid 3-Runner
A deeper 160 mm 1400 × 1200 mm pallet with a robust lengthwise base for demanding automated rack and transfer cycles. Its increased structural depth provides more room for rib geometry and reinforcement across repeated large-load movements.
Request a Quote- Dimensions
- 1400 × 1200 × 160 mm
- Reference weight
- 29.0 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue or custom
- Structure
- Grid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 6–12 tubes
- Static load
- 5,500 kg
- Dynamic load
- 2,000 kg
- Rack load
- 1,500 kg
AS/RS Performance Shaped Around This Footprint
Deeper body for a stronger large-format base
BH1412B retains the practical 1400 × 1200 mm load area but increases overall height to 160 mm. The deeper structure provides more room for rib geometry and reinforcement paths, making it the performance-focused lengthwise variant in the BH1412 group.
Made for repeated rack and transfer cycles
The three runners extend along 1400 mm to maintain stable bearing through long conveyor and rack interfaces. This model suits large unit loads that value base stiffness and repeated automated handling more than the 10 mm of vertical clearance saved by BH1412A.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
