BH1512 Grid 3-Runner
An extended 1500 × 1200 mm platform for long cartons, assemblies and industrial loads that need more deck length in automated storage. The familiar 1200 mm width keeps the lateral envelope controlled while the longer deck reduces end overhang.
Request a Quote- Dimensions
- 1500 × 1200 × 150 mm
- Reference weight
- 29.5 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue or custom
- Structure
- Grid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 6–12 tubes
- Static load
- 5,500 kg
- Dynamic load
- 2,000 kg
- Rack load
- 1,500 kg
AS/RS Performance Shaped Around This Footprint
Extra deck length for elongated loads
The 1500 × 1200 mm footprint supports long cartons, panel packs and industrial assemblies with less end overhang than mainstream 1200 or 1400 mm pallets. Its 1200 mm width remains familiar while the added length follows the geometry of the load.
Lengthwise bearing through dedicated AS/RS positions
Three runners track the full 1500 mm direction, creating continuous support lines for a dedicated large-format rack or conveyor route. The 150 mm height keeps this extended platform relatively low and preserves useful vertical space for the unit load.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
