BH1513 Grid 3-Runner
A wide 1500 × 1300 mm pallet for bulky rectangular loads that need both extended length and added lateral support. It bridges the slimmer BH1512 and near-square BH1514 for projects with a broad but clearly directional load profile.
Request a Quote- Dimensions
- 1500 × 1300 × 150 mm
- Reference weight
- 32.0 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue or custom
- Structure
- Grid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 6–12 tubes
- Static load
- 5,500 kg
- Dynamic load
- 2,000 kg
- Rack load
- 1,500 kg
AS/RS Performance Shaped Around This Footprint
Added width for bulky rectangular unit loads
BH1513 expands the 1500 mm platform to 1300 mm wide, giving bulky cartons, grouped containers and equipment packs more complete edge support. It sits between the slimmer BH1512 and near-square BH1514, making it a useful middle ground for custom load profiles.
Stable orientation for automated handling
The 1500 mm runner direction establishes the machine axis while the broader deck reduces unsupported load edges. This proportion works well in dedicated AS/RS cells where large packages remain rectangular but need more lateral stability during acceleration and transfer.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
