BH1612 Grid 3-Runner
A 1600 × 1200 mm long-load pallet for industrial assemblies and packaging that exceed standard automated warehouse footprints. It adds support along the load length without increasing the familiar 1200 mm width, keeping the transfer envelope focused.
Request a Quote- Dimensions
- 1600 × 1200 × 155 mm
- Reference weight
- 34.0 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue or custom
- Structure
- Grid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 6–12 tubes
- Static load
- 6,000 kg
- Dynamic load
- 2,000 kg
- Rack load
- 1,600 kg
AS/RS Performance Shaped Around This Footprint
A long platform without unnecessary width
BH1612 stretches to 1600 mm while holding width at 1200 mm, matching long equipment cartons, assemblies and component packs more closely than a broader square pallet. This helps keep the automated load envelope focused around the actual goods.
Continuous support along the extended axis
Lengthwise runners and configurable steel paths control the structure along its 1600 mm span. The underside view gives integrators a direct reference for rail spacing and transfer contacts when building a dedicated large-format AS/RS route.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
