BH1812 Grid 3-Runner
The longest 1800 × 1200 mm model in the range, built for oversized industrial loads moving through a dedicated AS/RS path. The 1800 mm deck supports elongated components and containers while the 1200 mm width maintains a controlled lateral footprint.
Request a Quote- Dimensions
- 1800 × 1200 × 155 mm
- Reference weight
- 38.0 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue or custom
- Structure
- Grid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 8–14 tubes
- Static load
- 6,500 kg
- Dynamic load
- 2,200 kg
- Rack load
- 1,800 kg
AS/RS Performance Shaped Around This Footprint
Maximum length for oversized industrial goods
BH1812 provides the family’s longest continuous deck for large components, elongated containers and oversized production loads. The 1200 mm width controls the lateral envelope while the 1800 mm axis gives the goods the support length they need.
A purpose-built AS/RS load carrier
The long runner paths and expanded reinforcement range support a dedicated automated handling route rather than a standard pallet position. Its proportions make the load direction unmistakable, helping profile checks, conveyors and storage equipment maintain one consistent orientation from entry to retrieval.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
