BH1208 Grid Full-Perimeter
A 1200 × 800 mm grid full-perimeter pallet for Euro-format loads that benefit from ventilation and four-sided base contact. Its narrow width supports dense lanes and standardized packaging patterns.
Request a Quote- Dimensions
- 1200 × 800 × 150 mm
- Reference weight
- 17.5 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue, green or custom
- Structure
- Grid deck · full-perimeter base
- Fork entry
- 4-way
- Steel-tube range
- 4–8 tubes
- Static load
- 4,000 kg
- Dynamic load
- 1,500 kg
- Rack load
- 1,000 kg
AS/RS Performance Shaped Around This Footprint
Euro-format deck with a continuous perimeter base
The familiar 1200 × 800 mm footprint fits modular cartons and compact automated lanes. Open deck cells reduce trapped debris and water, while the surrounding base improves support when the pallet orientation changes.
Automated handling characteristics
This model is useful for systems that combine standardized Euro loads with turntables or cross transfers. The full-perimeter base keeps the lower interface available along both long and short sides.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
