BH1211A Reinforced Solid 3-Runner
The 150 mm A version of the 1200 × 1100 mm reinforced solid pallet adds deck width while retaining a low structural profile. It suits loads that need more side support but must stay within a compact vertical interface.
Request a Quote- Dimensions
- 1200 × 1100 × 150 mm
- Reference weight
- 26.0 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue, green, white or custom
- Structure
- Reinforced solid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 6–12 tubes
- Static load
- 6,000 kg
- Dynamic load
- 2,000 kg
- Rack load
- 1,600 kg
AS/RS Performance Shaped Around This Footprint
Additional width in the lower A profile
The extra 100 mm width over BH1210 supports fuller carton patterns and wider fixtures without changing the 1200 mm travel length. Its proportions remain easy to orient in an automated lane.
Automated handling characteristics
The A structure favors systems where transfer and storage clearances reward a 150 mm profile. Reinforcement still extends through deck and runners to manage the wider load path.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
