BH1211B Reinforced Solid 3-Runner
The 160 mm B version shares the 1200 × 1100 mm footprint with BH1211A but adds structural depth and reinforcement capacity. It targets wider loads and longer unsupported transitions.
Request a Quote- Dimensions
- 1200 × 1100 × 160 mm
- Reference weight
- 28.0 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue, green, white or custom
- Structure
- Reinforced solid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 8–14 tubes
- Static load
- 6,000 kg
- Dynamic load
- 2,000 kg
- Rack load
- 1,700 kg
AS/RS Performance Shaped Around This Footprint
Same footprint, deeper B structure
Keeping the same plan dimensions lets a project upgrade vertical stiffness without redesigning the load footprint. The closed deck remains suitable for bags, cartons and loads with small contact feet.
Automated handling characteristics
The extra 10 mm of height and broader steel range provide more section depth for rack and transfer spans. This version is useful when BH1211A fits the goods but the equipment path demands a stronger vertical structure.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
