BH1410 Reinforced Solid 3-Runner
A long 1400 × 1000 mm reinforced solid pallet for wide cartons, panels and production fixtures. The 150 mm profile adds length while keeping both deck closure and equipment height compact.
Request a Quote- Dimensions
- 1400 × 1000 × 150 mm
- Reference weight
- 29.0 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue, green, white or custom
- Structure
- Reinforced solid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 8–14 tubes
- Static load
- 6,000 kg
- Dynamic load
- 2,000 kg
- Rack load
- 1,800 kg
AS/RS Performance Shaped Around This Footprint
Long closed deck with controlled width
The rectangular plan gives elongated goods more end support without consuming the width of a 1200 or 1400 mm square pallet. It is especially effective for loads that travel lengthwise through a fixed lane.
Automated handling characteristics
A defined long axis lets steel tubes and runners follow the primary bending direction. This produces a clear interface for chain conveyors, shuttle pickup and rack support under an extended closed deck.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
