BH1412A Reinforced Solid 3-Runner
A broad 1400 × 1200 mm reinforced solid pallet in a 150 mm A profile. It provides substantial closed deck area for wide cartons, bags and fixtures while limiting vertical space consumption.
Request a Quote- Dimensions
- 1400 × 1200 × 150 mm
- Reference weight
- 33.0 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue, green, white or custom
- Structure
- Reinforced solid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 8–16 tubes
- Static load
- 6,000 kg
- Dynamic load
- 2,200 kg
- Rack load
- 2,000 kg
AS/RS Performance Shaped Around This Footprint
Large deck area with the lower A structure
This footprint supports goods that need real width as well as length, reducing edge overhang on large unit loads. The solid surface distributes contact under flexible packaging and densely packed cartons.
Automated handling characteristics
The A profile keeps a 150 mm interface for projects with constrained rack pitch. Expanded steel positions and three runners carry the broad load toward known machine support lines.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
