BH1412B Reinforced Solid 3-Runner
The 170 mm B version brings greater structural depth to the same 1400 × 1200 mm closed deck as BH1412A. It is shaped for broad loads, wider support gaps and repeated rack cycles.
Request a Quote- Dimensions
- 1400 × 1200 × 170 mm
- Reference weight
- 36.0 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue, green, white or custom
- Structure
- Reinforced solid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 10–16 tubes
- Static load
- 6,000 kg
- Dynamic load
- 2,200 kg
- Rack load
- 2,200 kg
AS/RS Performance Shaped Around This Footprint
Deeper support beneath a broad closed deck
The footprint keeps large cartons, bags and fixtures fully supported, while the deeper body supplies more space for the reinforced load path. It is the higher-section counterpart to BH1412A.
Automated handling characteristics
The 170 mm height is valuable where a wide deck crosses defined conveyor and rack supports. Steel tubes can be arranged to control the broad span as the pallet repeatedly changes support conditions.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
