BH1414B Reinforced Solid 3-Runner
The deepest and broadest model in the family, BH1414B combines a 1400 × 1400 mm square closed deck with a 170 mm reinforced structure. It is intended for large centered loads and demanding automated support transitions.
Request a Quote- Dimensions
- 1400 × 1400 × 170 mm
- Reference weight
- 41.0 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue, green, white or custom
- Structure
- Reinforced solid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 10–18 tubes
- Static load
- 6,000 kg
- Dynamic load
- 2,400 kg
- Rack load
- 2,400 kg
AS/RS Performance Shaped Around This Footprint
Maximum deck breadth with the deep B structure
The square deck supports goods that occupy substantial area in both directions, while the B profile gives the reinforced body additional vertical depth. It is selected when the BH1414 plan size is right but the load path needs the stronger section.
Automated handling characteristics
Three runners define machine orientation beneath the symmetric deck, and the 170 mm section helps bridge transfers between different support patterns. This makes the model suitable for large automated unit loads with repeated rack cycles.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
