BH1111 Solid 3-Runner
A square 1100 × 1100 mm solid-deck pallet with a 165 mm overall height, combining balanced load coverage with a deeper runner structure. It suits square carton groups, drums and clean closed-loop handling.
Request a Quote- Dimensions
- 1100 × 1100 × 165 mm
- Reference weight
- 19.0 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue, green, white or custom
- Structure
- Solid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 4–8 tubes
- Static load
- 5,000 kg
- Dynamic load
- 1,500 kg
- Rack load
- 1,250 kg
AS/RS Performance Shaped Around This Footprint
Balanced square support with a deeper profile
Equal sides make load centering straightforward and support goods that spread similarly in both directions. The solid deck is especially useful when small packages or residues should not pass through the pallet.
Automated handling characteristics
The 165 mm height provides additional vertical section compared with the 150 mm formats. Although the footprint is square, the runners still tell conveyor and rack designers exactly which direction carries the continuous support.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
