BH1210 Solid 3-Runner
A versatile 1200 × 1000 mm solid-deck pallet with a 160 mm profile for mainstream industrial unit loads. The familiar rectangular footprint is easy to integrate while the closed deck supports bags and small-base cartons.
Request a Quote- Dimensions
- 1200 × 1000 × 160 mm
- Reference weight
- 20.5 kg
- Material
- HDPE
- Process
- Injection molded
- Colors
- Blue, green, white or custom
- Structure
- Solid deck · 3 runners
- Fork entry
- 4-way
- Steel-tube range
- 4–8 tubes
- Static load
- 5,000 kg
- Dynamic load
- 1,600 kg
- Rack load
- 1,250 kg
AS/RS Performance Shaped Around This Footprint
Mainstream industrial footprint with continuous support
The 1200 × 1000 mm platform balances usable deck area with a manageable machine envelope. It accommodates mixed carton patterns and returnable containers without the added width of a square pallet.
Automated handling characteristics
A 160 mm structure gives the runner openings and deck ribs additional depth for repeated automated handling. This model is a practical baseline when conveyors, racks and inbound handling all need one common footprint.
Structure & Dimensional Details
Steel layouts and load ratings can be adjusted for conveyor, shuttle and rack-support conditions.
